Ronstan Series 22 Captive Ball Intermediate Car

The Series 22 intermediate batten car is designed for 22 mm (7/8") tracks, featuring a durable alloy body and captive ball bearings for smooth operation. Its compact size and lightweight construction make it suitable for various sailboats.

Features:

• Captive ball bearings ensure smooth and reliable movement along the track
• Low-profile design reduces wind resistance and improves sail performance
• Lightweight alloy body offers strength without adding unnecessary weight
• Ball joint link provides articulation with over 105 deg. movement for flexible sail adjustment
• Compatible with luff groove tracks for easy installation on soft luff and fully battened sails
• Threaded slug installation simplifies mounting without mast removal
• Durable Torlon bearings resist wear and maintain long-term performance

Specifications:

• Track Size: 22 mm (7/8")
• Dimension A: 54 mm (2 1/8")
• Dimension B: 34 mm (1 11/32")
• Dimension C: 46 mm (1 25/32")
• Dimension D: 18 mm (23/32")
• Width: 47 mm (1 7/8")
• Weight: 102 g (3.6 oz)
• Car Body Material: Alloy
• Ball Bearing Material: Torlon

Compatibility:

• Monohull Size: Up to 18 m (60') or sail area 70 m2 (753sq. ft.)
• Multihull Size: Up to 13 m (43') or sail area 57 m2 (614sq. ft.)

Installation Instructions

Track Series 22CB Batten System Selector
