Racor Diesel Spin-on Fuel Filter/Water Separator Assembly - 460R2

Racor's 400 series fuel filter water separators are specifically designed to handle todays tough diesel filtration problems. These units feature a standard in-head fuel priming pump and are different from one another only in flow capacity and element size.

Features:

• Reusable, clear plastic bowl
• Replacement cartridge elements exhibit high dirt-holding capacity and long service life
• Corrosion-resistant coatings and construction
• Product is built in an ISO TS 16949 quality system environment to ISO 14001 Environmental requirements
• Patented Aquabloc® media comes in 2 micron rating

Specifications:

• Product Series: Spin-on 400, Diesel
• Flow Rate: 60 GPH (227 LPH)
• Bowl Material: Clear engineering plastic
• Integral Primer Pump Included: Button priming pump (diesel)
• Mounting: Bracket included
• Heater Power Rating: No Heater
• Micron Rating: 98% @ 4 Micron
• For Fluid Type: Diesel
• Clean Pressure Drop: 0.39 psi, 2.7 kPa
• Filter Element Type Included: 2 Micron Aquabloc spin-on
• Compatible Elements:
  • R60S = 2 Micron
  • R60T = 10 Micron
  • R60P = 30 Micron
• Dimensions (D x W x H): 4.8" x 4.5" x 11"
• Head Material: Aluminium alloy
• Maximum Operating Pressure: 30 psi, 207.0 kPa
• Port Size: 3/8"-18 NPTF (SAE J476)
• Number of Ports: 2 inlet / 2 outlet
• Operating Temperature: -40 to 250° F (-40 to 121° C)
• Maximum Fluid Temperature: 190° F (88° C)

Product Data Sheet
