Lopolight 101 Series Combined Side Light - 1 NM

This combined sidelight features a Silver anodized aluminum housing with a flat base and a 1 NM visibility range. It includes a 2.5 m (8.2') marine-grade cable and is designed for horizontal mounting on vessels under 12 m (39.4').

Features:

• Durable Silver anodized aluminum housing with corrosion-resistant finish
• Integrated red and green lenses providing 112.5 deg. light sectors for navigation
• Flat base design allows secure horizontal mounting with a low-profile appearance
• Includes 2.5 m (8.2') shielded cable for reliable electrical connection
• Waterproof construction rated to IP68 for extended marine use
• Wide operating voltage range supports 10V to 32V DC systems
• Low power consumption with efficient 1.4W draw for energy savings
• Temperature resistant from -25°C to 55°C (-13°F to 131°F) for versatile environments
• Stainless steel hardware ensures long-lasting corrosion resistance

Specifications:

• Visibility: 1 NM
• Dimensions (Diameter x Depth): 3.6" x 1.4" (92.5 x 58 mm)
• Operating Voltage: 10V - 32V DC
• Power Draw: 1.4W
• Current Consumption (12V): 87mA
• Current Consumption (24V): 48mA
• IP Rating: IP68
• Operating Temperature: -25°C to 55°C (-13°F to 131°F)
• Weight: 0.55 kg (19.3 oz)
• Minimum Wire Gauge: 0.5 mm² (22 AWG)
• Material: Anodized aluminum, PMMA lens, stainless steel

Compatibility:

• Suitable for vessels under 12 m (39.4') in length

Included:

• (1) Combined sidelight with 2.5 m (8.2') cable
• (1) Installation guide
