Garmin GT15M-IH In-Hull CHIRP Transducer

The GT15M-IH transducer is ideal for boats that want to install the transducer inside a fiberglass hull and not on the transom where cavitation could cause issues. It can be used with a hull deadrise angle between 0 and 25 deg. and is excellent for boats traveling at high speeds that want to maintain accurate depth readings.

Features:

• 8-pin transducer with 4 plastic tanks
• Mid-band CHIRP traditional sonar (85-165 kHz) and has a power rating of 600W
• May be used in conjunction with a GT30-TM transducer and an adapter cable so you can maintain depth at high speeds and scanning capabilities at trolling speeds
• Transducer kit comes with installation instructions - follow the instructions carefully to avoid damaging your boat

Specifications:

• Frequency: CHIRP Mid-band (85-165 kHz)
• Power: 600W
• Beamwidth: 24°-13°
• Maximum depth: 1,900'
• Cable length: 20'
• Transducer depth/speed/temperature: Depth
• Number of pins: 8-pin
• Supported deadrise/transom angles: 0°-25° deadrise

Included:

• GT15M-IH transducer
• 4 plastic tanks
• Mounting hardware
• Documentation

Installation Instructions
