Easysea Flipper Foldable Winch Handle

The last winch handle you'll ever need. Featuring a universal star stud to fit any winch, the Flipper handle is made to last, with a frame crafted from CNC-milled 6082 anticorodal aluminum and joints made from stainless steel 316L. Flipper is the only handle that doesn't need to be removed after each maneuver - it simply folds up. Furthermore, it eliminates the risk of losing it at sea!

Compared to the standard 8" Flipper version, the 10" Flipper Max features a longer lever, providing greater mechanical advantage and reducing the effort required during maneuvers.

Features:

• Foldable by Design: The patented FlipFold system folds it onto the winch permitting you to ease and wrap the sheet without ever removing the handle
• Never Lost Overboard: Always attached to the winch, always ready: no more digging in lockers, no more handles overboard
• 4 Positions, One Handle: From closed to extended with a ratchet lever: you choose between speed and power, maneuver by maneuver

Specifications:

• Material: 6082 Anodized aluminum, 316L stainless steel
• 8" Flipper Model:
  • Recommended Boat Length: 6 - 11 m (19' - 36')
  • Recommended Winch Sizes: 6, 7, 16, 30, 40, 45, 46
  • Model Number: FS-101-1
  • Material: Aluminum 6082
  • Weight: 522 g (1.15 lbs)
  • Dimensions:
    • When Closed: 142 mm (5.59")
    • When Open: 204 mm (8")
    • When Extended (Ratchet Position): 314 mm (12.36")
  • Maximum Working Load: 350 kg (771 lbs)
  • Breaking Load: 700 kg (1543 lbs)
• 10" Flipper Max Model:
  • Recommended Boat Length: 11 m (36') or greater
  • Recommended Winch Sizes: 45, 46, 50, 55, 65, 70
  • Model Number: FM-101-1
  • Weight: 722 g (1.59 lbs)
  • Dimensions:
    • When Closed: 190 mm (7.48")
    • When Open: 254 mm (10")
    • When Extended (Ratchet Position): 379 mm (14.92")
  • Maximum Working Load: 400 kg (881 lbs)
  • Breaking Load: 800 kg (1763 lbs)
