Lofrans Project 1000 Vertical Windlass - with Gypsy/Drum

Incorporates contemporary styling into a smooth shape that looks great on any foredeck. The unique motor design enables the operator to lower the anchor to the sea bed floor safely and quickly - a tremendous benefit in a tight anchorage.

Features:

• Recommended for hulls 29' - 45'
• Topworks constructed of corrosion-resistant chromed-bronze
• Self-lubricating, aft-facing Delrin pressure finger assists in seamless rope/chain transition
• 1000W, 2-speed motor with 52:1 gearbox ratio provides fast, powerful retrieval and accelerated payout
• Unique lockable clutch on LP models to avoid accidental deployment
• Rope/chain combination wheels, optional remote free-fall
• Manual override with handle included
• Mainshaft and chainpipe holes are the same diameter and can be cut with a simple hole saw
• Keylocks in the black-anodized gearbox flange make connecting the gearbox and topworks a simple, one-person task

Standard Equipment:

• Rope/Chain management system
• Watertight dual-direction control box
• Neoprene deck gasket
• (2) heavy-duty covered footswitches
• Manual override clutch handle

Specifications:

• Maximum Pull: 1500 lbs
• Chain Size (Short Link): 5/16"
• Line Size: 9/16" - 5/8"
• Power Supply: 12V DC
• Motor (Watts): 1000W
• Retrieval Speed (No Load): 79'/min
• Retrieval Speed (Working Load): 52'/min
• Amperes (No Load): 70
• Amperes (Working Load): 110
• Max. Deck Thickness 1 9/16"
• Weight: 55 lbs (25 kg)
• Max. Working Load: 500 lbs
